MPS3001 Series Pulse Radar Level Meter 150℃ Process Temperature Algorithmic Intelligence)

  MPS3000 series pulse radar level meter (150℃ Process temperature/high-accuracy/Algorithmic intelligence )

  MPS3000 Series pulse radar bit meter is a "overlooking" measurement system based on the principle of time stroke. The instrument is fired from a radar antenna1 mW micropower microwave pulse (such as 26G frequency radar, namely send a △ t-1 nS pulse, superimposed 26GHz sine wave signal), thisThe pulse travels in space at the speed of light, touches the surface of the measured medium, and part of its energy is reflected back and received by the same antenna. Emission pulse and receiving pulseThe time interval of flushing is proportional to the distance of the antenna to the surface of the measured medium.

Product characteristics:

1. No blind spots

2. High precision, two-line manufacturing technology, is an alternative product of differential pressure, magnetostrictive, radio frequency guide, magnetic flip plate and other position instruments.

3. It is not affected by pressure change, vacuum, temperature change, inert gas, smoke, steam and other environment, and the measurement results are stable and reliable.

4. Dual CPU, stronger hardware processing ability, more intelligent algorithm and more stable system

5.Double warehouse case, standard with magnetic keys, high protection level

6. Special manual operator, to support remote debugging and diagnosis

7. Standard anti-surge protector, level 4 electromagnetic compatibility

8. Suitable for high temperature working conditions, up to 150℃ process temperature, when using high temperature extension antenna can reach 350℃

9. Instrument graphics dot array liquid crystal supports the field waveform display and establish false echo and other complex operations. Reduce the instrument operation difficulty and maintenance workload.
