Mps7000 Series Level Meter Radar Level Gauge 0.1-50m 100m 150m 120Ghz - 130ghz Fm Wave Radar
| Place of Origin | Shanghai, China |
|---|---|
| Brand Name | CQCY |
| Certification | CCS/ 3A/ TUV-SII2/3 / IEC Ex/ATEX/CE/NEPSI |
| Model Number | MPS7000 Series |
| Minimum Order Quantity | 1set |
| Price | USD+50 dollars to 1000 dollars+1set |
| Packaging Details | Carton packing |
| Delivery Time | 10-30 work days |
| Payment Terms | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability | 10000+1set+per day |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Measurement Accuracy | <+2mm | Measurement Resolution | 0.01mm (50m Range) / 0.1mm (100m Range) |
|---|---|---|---|
| Emission Frequency | 120GHz~130GHz, And The FM Scan Frequency Width Is 10 GHZ | Support The Standard | HART, MODBUS, And Protocol |
| Highlight | Mps7000 Series Level Meter,Level Meter 100m,Radar Level Gauge 150m |
||
Product Description
Mps7000 Series Radar Level Gauge(Measuring Range /0.1-50/100/150m,120 Ghz-130ghz Fm Wave Radar, )
MPS7000 Series 120GHz-130GHZFMCW radar products (also called THZ terahertz radar), because it adopts higher frequency than Ku band radar THz band, in the remote target detection, strong smoke dust environment, long distance imaging, multispectral imaging has important applications, and able to detect smaller than microwave radar and achieve more accurate positioning, with higher resolution and stronger confidentiality.
1.120 GHZ-130GHz FM wave radar, the world's first terahertz radar used in the field of industrial measurement
2.10GHz super large FM scan frequency width, wide applications
3.320 * 240dot TFT color LCD display, easy operation, friendly interface
4. Support the standard HART, MODBUS, and protocol
5. Support the upper computer setting software, LCD keyboard module, tank side table and other operations and configuration methods
6.24VDC and 220VAC two power supply models
7.Simple installation structure, adapt to various installation forms on site
